18
SD220/SD230 OUTPUT SIGNALS
Single/Double Outputs - Failsafe Mode
Sourcing Sinking
SNGL
DBL
missing missingsingle double
SNGL
DBL
missing missingsingle double
Single/Double Outputs - Compatibility Mode
SinkingSourcing
SNGL
DBL
missing missing
single
double
SNGL
DBL
missing missingsingle double
No Tab/Tab Outputs - Failsafe Mode
Sourcing Sinking
No Tab/Tab Outputs - Compatibility Mode
Sourcing
Sinking
CHANNEL 2 - DISCHARGE
CHANNEL 1 - INFEED
TAB
NO TAB
no end no end end
with tab
end
without tab
TAB
NO TAB
no end no end
end
with tab
end
without tab
TAB
NO TAB
no end no end
end
with tab
end
without tab
TAB
NO TAB
no end no end end
with tab
end
without tab
