Prime Controls SD220 - Holding Registers (400001) (Read;Write)

33
K – Flash pulse detection bit is valid. It is possible that a report from the LH200 is delayed due to retries. In this case, the timing of the report
message may prevent proper sampling of the AUX input. In this case, this bit is set to zero and the validity of the flash detection bit cannot be
determined.
Holding Registers (400001) (Read/Write)
Entity
Number
ET230 Tags
Name
Meaning
400001
GageTolRd &
GageTolValue &
GageTolStrobe
GageTol
Gauging tolerance in percent
400002
Delta
Minimum panel to tab delta (SD225 only)
400003
OverlapPercentage
Overlap
Off-press shell overlap allowance in percent
400004
DataInvertContrlRd &
DataInvertControlValue
&
DataInvertControlStrobe
DisplayInv
Display invert (100 to 0 vs 0 to 100)
400005
SD230Gain
Gain
Receiver gain (0 to 255)
400006
GageThreshold
GageThreshold
Single to double or tab to no-tab threshold
400007
GapThresh
GapThresh
Shell to no shell data threshold
400008
DAcqGadThresh &
DAcqGapThreshValue
&
DAcqGapThreshStrobe
DAcqGapThresh
Shell/no-shell threshold for data acquisition
400009
Frequency
Frequency
Transmitter frequency
400010
Not used
400011
TotalMsgCnt &
ClearDiagStrobe
BusMsgCt
Modbus total message count
400012
HandledMsgCnt &
ClearDiagStrobe
HandledMsgCt
Modbus handled message count
400013
CRCerrorCnt &
ClearDiagStrobe
CRCErrCt
Modbus CRC error count
400014
ExceptionMsgCnt &
ClearDiagStrobe
ExceptionCt
Modbus exception response count
