All values listed with “Atomic Read” are to be read as a single block. They use a data locking mechanism in the SD230 code to prevent update to
these values once a read is initiated and until it is completed for all parameters.
Reports are read by setting two tags: Prime_ReportEnableChn which selects the channel from which to read, and Prime_ReportIndex which
selects which of the eight reports stored in the SD230 is read. Prime_ReportIndex = 0 selects the most recent report while Prime_ReportIndex =
7 selects the seventh most recent. Acceptable values for Prime_ReportIndex are 0 through 7.
Report number is a modulo 32768 count of the reports sent by the LH200. This count originates in the LH200 and is used to detect
dropped/missing reports by the application program. When the LH200 online coil is zero, the report number shall be set to 65535 to indicate the
report parameters may be invalid.
Interpretation of the Gage Attrib Flag 300002
0 -> Single/Double Detection
1 -> On-Press Tab Detection
2 -> Off-Press Tab Detection
Tolerance Adjustment Allowed
Overlap Adjustement Allowed
Interpretation of the LH200 Result Flag 300316
Peak Value Exceeded (L) [light leak]
Flash Detect (F) [SL100 strobe]
Flash Detect Valid (K) [SL100 strobe]
D – Average dark current exceeded the dark limit, Bit 0
N – dark spread exceeded the spread limit, Bit 1
L – peak value exceeded the leak limit, Bit 2
F – Flash pulse detected, Bit 3
