Prime Controls SD220 - Discrete Coil Inputs (100001) (Read Only)

27
Entity
Number
ET230 Tags
Name
Meaning
000036
N/A
Dark Ref Fast
Average
LH200 – Reports Flag (B15)
Discrete Coil Inputs (100001) (Read Only)
Entity
Number
ET230 Tags
Name
Meaning
N/A
Prime_ModbusFault
Modbus Fault
Modbus Fault detected by PLC (PLC
tag)
100001
BitGroup2.DIPsw.0
DIPSw1
DIP Switch 1 input
100002
BitGroup2.DIPsw.1
DIPSw2
DIP Switch 2 Input
100003
BitGroup2.DIPsw.2
DIPSw3
DIP Switch 3 input
100004
BitGroup2.DIPsw.3
DIPSw4
DIP Switch 4 input
100005
BitGroup2.DIPsw.4
DIPSw5
DIP Switch 5 input
100006
BitGroup2.DIPsw.5
DIPSw6
DIP Switch 6 input
100007
BitGroup2.DIPsw.6
DIPSw7
DIP Switch 7 input
100008
BitGroup2.DIPsw.7
DIPSw8
DIP Switch 8 input
100009
BitGroup2.SD230_IO.0
InputReg1
Calibrate pushbutton input
100010
BitGroup2.SD230_IO.1
InputReg2
External CAL input
100011
BitGroup2.SD230_IO.2
InputReg3
AUX input
100012
BitGroup2.SD230_IO.3
RunFlag
Machine is running flag
N/A
Reserved
100018
BitGroup4.LH200_IO.0
Cal Fail
Indicates LH200 was unable to
calibrate
100019
BitGroup4.LH200_IO.1
Cal Busy
Indicates LH200 is busy with
calibration
100020
BitGroup4.LH200_IO.2
LH200 Online
LH200 – Indicates that an LH200 is
connected and communicating
100021
BitGroup4.LH200_IO.3
Freerun Mode Active
LH200
100022
BitGroup4.LH200_IO.4
TriSense
SD230 Parameter Setting
100023
BitGroup4.LH200_IO.5
Flash Detect Input
SD230 Parameter Setting
