26
Entity
Number
ET230 Tags
Name
Meaning
000013
N/A
Reserved
000014
N/A
Reserved
000015
N/A
Reserved
000016
N/A
Reserved
000017
BitGroup3.LH200_IO.0 &
FreeRunValue &
FreeRunStrobe
Free Run
LH200 – Freerun Mode
000018
BitGroup3.LH200_IO.1 &
AutoAdjustValue &
AutoAdjustStrobe
Auto Adjust (Bias)
LH200 – Auto Adjust Bias Mode
000019
BitGroup3.LH200_IO.2 &
CalOffsetValue &
CalOffsetStrobe
Cal Offset
LH200 – Trigger Calibrate Offset Adjustment
000020
N/A
Unhide Reports
LH200 – Unhide reports mask
000021
N/A
Reserved
LH200 – Reports Flag (B0)
000022
N/A
Result Flags
LH200 – Reports Flag (B1)
000023
N/A
Temperature
LH200 – Reports Flag (B2)
000024
N/A
Leak Factor
LH200 – Reports Flag (B3)
000025
N/A
Peak Value
LH200 – Reports Flag (B4)
000026
N/A
Sample Sum
LH200 – Reports Flag (B5)
000027
N/A
Sample High Value
LH200 – Reports Flag (B6)
000028
N/A
Sample Count
LH200 – Reports Flag (B7)
000029
N/A
Segment Count
LH200 – Reports Flag (B8)
000030
N/A
Dark Spread
LH200 – Reports Flag (B9)
000031
N/A
Dark Max
LH200 – Reports Flag (B10)
000032
N/A
Dark Min
LH200 – Reports Flag (B11)
000033
N/A
Dark Average
LH200 – Reports Flag (B12)
000034
N/A
DAC
LH200 – Reports Flag (B13)
000035
N/A
Dark Ref Slow
Average
LH200 – Reports Flag (B14)
