Prime Controls SD220 - Register Inputs (300001) (Read Only)

28
Entity
Number
ET230 Tags
Name
Meaning
100024
BitGroup4.LH200_IO.6
Machine Running Flag
LH200
100025
N/A
Unhide Report parameters
LH200
100026
BitGroup5.LH200_IO.0
Peak Value Exceeded Flag (L)
LH200 – Result Flag
100027
BitGroup5.LH200_IO.1
Dark Spread Fail Flag (N)
LH200 – Result Flag
100028
BitGroup5.LH200_IO.2
Dark Level Fail Flag (D)
LH200 – Result Flag
100029
BitGroup5.LH200_IO.3
Flash Detect Flag (F)
LH200 – Result Flag + AUX Input
100030
BitGroup5.LH200_IO.4
Flash Detect Valid Flag (K)
LH200 – Result Flag + AUX Input
The result flags are also readable in a packed binary form as a Register Input.
Register Inputs (300001) (Read Only)
Entity Number
ET230 Tags
Name
Meaning
300001
NetworkID
Modbus network ID (1-32)
300002
GageAttrFlag
GageAttrFlag
Gauging attributes
300003
MaterialCode
MaterialCode
Shell and tab material code
300004
ScaledGageDispVal
ScaledGageDispVal
Gage value (0 to 255)
300005
FaultReg
FaultReg
Fault reporting register
300006
WatchdogCounter
WatchdogReg
Watchdog counter register
300007
NuOfChan
NodeCt
Count of SD units on the network
300008
Not used
300009
Not used
300010
SwLabels[0]
SwLabel1
DIP Switch 1 label text (Packed Bytes)
300020
SwLabels[1]
SwLabel2
DIP Switch 2 label text (Packed Bytes)
300030
SwLabels[2]
SwLabel3
DIP Switch 3 label text (Packed Bytes)
300040
SwLabels[3]
SwLabel4
DIP Switch 4 label text (Packed Bytes)
300050
SwLabels[4]
SwLabel5
DIP Switch 5 label text (Packed Bytes)
300060
SwLabels[5]
SwLabel6
DIP Switch 6 label text (Packed Bytes)
300070
SwLabels[6]
SwLabel7
DIP Switch 7 label text (Packed Bytes)
300080
SwLabels[7]
SwLabel8
DIP Switch 8 label text (Packed Bytes)
300091
ProfileSize
ProfileSize
Number of data points in the profile
