29
Entity Number
ET230 Tags
Name
Meaning
N/A
Prime_ProfileEnableChn
Profile Channel Select
Selects channel for active profile
capture (PLC tag)
300092
ProfileData &
Prime_ProfileEnableChn
ProfileData
Data buffer (200 packed bytes read as
100 16 bit registers), data set selected
by ProfileIndex
300292
N/A
FirmwareVersion
Firmware version no (dd.dd x 100)
N/A
Reserved
300300
N/A
LH200 Firmware Version
LH200 Firmware version no (dd.dd x
100)
N/A
Prime_LH200ReportEnableChn
Report Channel Select
Selects channel for active report
capture (PLC tag)
N/A
Prime_LH200ReportIndex
Report Index Select
Selects report # for active report capture
(PLC tag) – Allows PLC to select
between reports N to N-7 below.
(Range: 0-7)
Start of table of 8 LH200 reports
300301
LH200_Report.Report[0] &
Prime_ReportEnableChn &
Prime_ReportIndex
Report Number
LH200 – Atomic Read (modulo 32768)
300302
LH200_Report.Report[1] &
Prime_ReportEnableChn &
Prime_ReportIndex
Dark Ref Fast Average
LH200 – Atomic Read
300303
LH200_Report.Report[2] &
Prime_ReportEnableChn &
Prime_ReportIndex
Dark Ref Slow Average
LH200 – Atomic Read
300304
LH200_Report.Report[3] &
Prime_ReportEnableChn &
Prime_ReportIndex
DAC
LH200 – Atomic Read
300305
LH200_Report.Report[4] &
Prime_ReportEnableChn &
Prime_ReportIndex
Dark Average
LH200 – Atomic Read
300306
LH200_Report.Report[5] &
Dark Min
LH200 – Atomic Read
