Prime Controls SD220 - Page 36

31
Entity Number
ET230 Tags
Name
Meaning
300316
LH200_Report.Report[15] &
Prime_ReportEnableChn &
Prime_ReportIndex
Result Flags
LH200 – Atomic Read + Synth AUX bits
300317-332
N/A – Use Prime_ReportIndex
to select.
Report (N-1)
LH200 – Atomic Read
300333-348
N/A – Use Prime_ReportIndex
to select.
Report (N-2)
LH200 – Atomic Read
300349-364
N/A – Use Prime_ReportIndex
to select.
Report (N-3)
LH200 – Atomic Read
300365-380
N/A – Use Prime_ReportIndex
to select.
Report (N-4)
LH200 – Atomic Read
300381-396
N/A – Use Prime_ReportIndex
to select.
Report (N-5)
LH200 – Atomic Read
300397-412
N/A – Use Prime_ReportIndex
to select.
Report (N-6)
LH200 – Atomic Read
300413-428
N/A – Use Prime_ReportIndex
to select.
Report (N-7)
LH200 – Atomic Read
300429
N/A
DIAG Missed Reports
SD230 Diagnostic Counters
300430
N/A
DIAG Bad Shifts
SD230 Diagnostic Counters
300431
N/A
DIAG Bad CRC
SD230 Diagnostic Counters
300432
N/A
DIAG Pending
SD230 Diagnostic Counters
300433
N/A
DIAG Double Pending
SD230 Diagnostic Counters
300434
N/A
DIAG Partial Messages
SD230 Diagnostic Counters
300435
N/A
DIAG Fails
SD230 Diagnostic Counters
300436
N/A
DIAG Retries
SD230 Diagnostic Counters
300437
N/A
DIAG Bad CRC
LH200 Diagnostics Counters
300438
N/A
DIAG Short Msg
LH200 Diagnostics Counters
300439
N/A
DIAG Fails
LH200 Diagnostics Counters
300440
N/A
DIAG Retries
LH200 Diagnostics Counters
