Entity
Number
ET230 Tags
Name
Meaning
400015
NoResponseMsgCnt &
ClearDiagStrobe
NoRespCt
Modbus no-response count
400016
CharOverrunCnt &
ClearDiagStrobe
CharORCt
Modbus character overrun count
400017
NAKresponseCnt &
ClearDiagStrobe
NAKRespCt
Modbus NAK response count
400018
BusyResponseCnt &
ClearDiagStrobe
BusyRespCt
Modbus busy response count
400019
ProfileIndex &
ProfileIndexValue &
ProfileIndexStrobe
BufferIndex
Profile index for retrieval of current and past
profiles: 0 to 9, 0 is most recent
N/A
Reserved
400030
LH200DrkLimit &
LH200DrkLimitValue &
LH200DrkLimitStrobe
Dark Limit
LH200 (1-4000, 30 default)
400031
LH200Gain &
LH200GainValue &
LH200GainStrobe
Gain Value
LH200 (10-100, default 100)
400032
LH200LeakLimit &
LH200LeakLimitValue &
LH200LeakLimitStrobe
Leak Limit
LH200 (1-4000, 500 default)
400033
LH200SprdLimit &
LH200SprdLimitValue &
LH200SprdLimitStrobe
Spread Limit
LH200 (1-4000, 500 default)
400034
LH200Bias &
LH200BiasValue &
LH200BiasStrobe
Bias
LH200 (1-100, 30 typical)
In cases where three PLC tags are listed as in: GageTolRd & GageTolValue & GageTolStrobe. The first PLC tag (GageTolRd) is the current value of
this parameter in the SD230 or LH200. The second PLC tag (GageTolValue) is the value that will be written to the SD230/LH200 when the third
value (GageTolStrobe) is set to minus one (-1). The third tag is set to zero upon completion of the writing action.
