Getting Started 5
F. APPLYING POWER
1. Locate the power adapter supplied with your printer.
2. Place one end
of the adapter
cord into the
power port on
the rear panel
of the printer.
3. Plug the power
cord of the
adapter into an
available wall
outlet or surge
protecting
power strip.
Once the power cord is connected, the printer can be
switched on and off using the power switch.
G. INSTALLING THE DRIVER AND SOFTWARE
The Color Label Printer is designed to be used with nearly
any IBM-PC® or compatible running Windows 2000/XP or a
Macintosh running OS 10.2 or higher. The printer is equipped
with a USB 1.0/2.0 port. This port is the means through which
it receives data from your computer. To connect the printer to
your computer, use the included shielded USB cable. The soft-
ware installs as follows:
PC Installation
1. Insert the Installation CD into your computer. In a few
moments the installer program should launch
automatically. If not, perform the following steps:
a. Double click My Computer Icon, then double click
the icon of the appropriate CD drive containing the
software installer disc.
b. Double click INSTALL.exe then click the Quick Start
Install Button.
2. Follow the on screen instructions to install the software.
These steps are illustrated below:
a. Apply power
To Next Page
