32
Chapter 2 Loading Roll Media
9. Close the printhead by pressing down on both sides of the front of the
printhead assembly.
10. Adjust the media pressure control knob to match the width of the label
stock in use.
Legend:
1) Printhead Assembly
2) Media Pressure Control Knob
CAUTION
Ensure the printhead is down and latched before attempting to print.
Failure to do so may cause a premature failure of the printhead.
Media Width
Pressure Control
Knob Settings
2 inches or Less 2 inches
Greater Than 2 inches 4 inches
1
2
To Next Page
