Pro-Form 350 CSX - ASSEMBLY - STEP 3: SEAT ASSEMBLY; Attach Seat to Seat Frame; Attach Seat Frame to Carriage

8
7
7. Attach the Seat Frame (9) to the Seat Carriage
(7) with four M8 x 40mm Screws (28). Start all
the Screws, and then tighten them.
9
7
28
28
6
6. Orient the Seat (10) and the Seat Frame (9) as
shown.
Attach the Seat (10) to the Seat Frame (9) with
four M6 x 40mm Screws (27). Start all the
Screws, and then tighten them.
10
27
27
9
