Cable Diagram
The diagram below shows the proper routing of the High Cable (73) and the Low Cable (72). The numbers show
the correct route for each Cable. Make sure that the Cables are routed correctly, that the pulleys move
smoothly, and that the cable traps do not touch or bind the Cables. Incorrect cable routing can damage
t
he training system.
High Cable (73)
Large Ball
Low Cable (72)
2
8
9
1
3
7
6
4
10
5
Cable ID Chart
(72)
(73)
3
2
1
6
5
