10
6. Attach the Left Handrail (83) to the Left Upright
(79) with two 5/16" x 2 1/2" Screws (10) and
two 5/16" Star Washers (11). Make sure that
the Upright Wire (78) is resting to the side as
shown and is not pinched. Fully tighten the
Screws.
Attach the Right Handrail (86) with two 5/16" x
2 1/2" Screws (10) and two 5/16" Star Washers
(11). Fully tighten the Screws.
Remove the wire tie from the Upright Wire (78).
88
6
86
83
79
78
11
10
11
10
7. If there are four screws (C) in the locations
shown, remove and discard them.
7
C
C
Wire
Tie
To Next Page
