HOW TO ADJUST THE DRIVE BELT
If you feel the pedals slip while you are pedaling, even
when the resistance is adjusted to the highest level,
the drive belt may need to be adjusted.
To adjust the drive belt, first use a standard screwdriver
to carefully pry off the Right Hub Cover (33) and the
Left Hub Cover (84). Then, remove the two indicated
M4 x 19mm Screws (87) and the Hub Shield (85).
Next, loosen, but do not remove, the M10 Flange Nut
(75) on each side of the exercise bike (only one side is
shown).
Next, tighten the Adjustment Nut (49) on each side
of the exercise bike (only one side is shown) until the
Drive Belt (46) is tight.
Then, firmly tighten the M10 Flange Nuts (75).
Pedal the exercise bike and test the adjustment.
Repeat the above procedure, if necessary. When the
drive belt is properly tightened, reattach the parts that
you removed.
33
84
75
49
46
85
87
