Pro-Form XP 440 R User Manual

10
11
12
13
11. Orient the Seat (8) and Seat Frame (7) assembly
as shown. Attach the Seat Frame to the Seat
Carriage (3) with four M8 x 40mm Screws (58).
12. Orient the Backrest (6) as shown. Attach the
Backrest to the Backrest Frame (5) with two M6
36mm Screws (69).
8
6
5
7
3
58
58
69
22
41
Receptacle
13. Plug the Seat Frame Pulse Wire (22) into the
receptacle in the Left Seat Shield (41).

Pro-Form XP 440 R Specifications

General

Brand	Pro-Form
Model	XP 440 R
Category	Exercise Bike
Language	English
