Pro Spot i5 - Double-Sided Welding; SA-0053 Double-Acting Spot Gun

5 - Double-Sided Welding
The spot gun is used for the following weld programs:
• Two-Sided spot welding - HSS Galvanized steel, Mild steel, Weld Bonding,
Boron Steel, Pulse welding and OEM, Custom Modes
(see section 4.8 “Setting the default welding programs”)
Figure 5.1 SA-0053 Spot Gun - Component Diagram
Page 17
All Info Copyright © Pro Spot International Inc.
Push this button to open electrodes wide. Push this button to close electrodes and weld.
5.1.2 Using the Double-Acting Gun
5.1.1 SA-0053 Component Diagram
5.1 SA-0053 Double-Acting Spot Gun
5) Double-Sided Welding
i5
Release Trigger Switch
Tool Balancer Hook
Welding Arm
Weld Trigger Switch
Clamping Handle
Shank
Welding Cap
Cable / Tube Input
