EN-16
2 Stroke
In Manual Welding Mode the unit will weld conti-
nuously while the torch trigger is pressed (Welding
ON). Releasing the torch trigger will interrupt welding
immediately (Welding OFF).
4 Stroke
In Automatic Welding Mode the welding process is
performed as follows:
• first torch trigger pression (Welding ON as current
is fed, Slope Up as set till the set current value
is reached)
• first torch trigger release
• second torch trigger pression (Slope down and
Final Current)
• second torch trigger release (Arc OFF and Post Gas)
Current
Normal / Pulsed
V2 CUT
Arc voltage value over which the arc switches off
Automatic - 16V to 34V - OFF
PRE GAS
Regulation of the Gas outflow before the welding
start (0 -25 sec)
I MIN VAL
Regulation of the base current value (5 till set current
in A)
FREQUENCY
Regulation of the pulsation frequency to grant excellent
quality and apparance results (1-500Hz)
WAVE BAL.
Corresponds to the Time ON percentage (20% -
80%); adjusting the duty cycle in pulsed mode allows
the peak current keeping for a longer or shorter time.
Slope Up
Regulation of the time needed by the welding current
to reach the set value (0 – 10 Sec)
Down Slope
Regulation of the time needed by the welding current
to reach the final current value (Crater Filler 0 – 10
Sec)
Crater VAL
Regulation of the Final Current Value or Crater Filler
(5 till set current in A)
Post Gas
Regulation of the gas outflow time at the end of
welding (0 – 25 Sec.)
Use the Mode Key - 1 - to go back to the TIG main
screen after parameters are adjusted.
Right Regulation Knob - Down Slope
Regulation of the time needed by the welding current
to reach the final current value (Crater Filler OFF /
0 – 10 Sec)
Navigation key
adjusts Post Gas value on a range from 0 to 25 sec
Left Regulation Knob - Current
adjusts the welding current (A) on a range from 5 to
maximum current value
Save & Recall
for saving and recalling the points that the operator
can customize. Refer to the chapter “Save & Recall”.
4
7
5
6 8
To Next Page
