Pro Spot SP-5 - MIG;MAG Quick Start Parameter Guide; Synergy OFF;ON Parameter Summary; Pulsed MIG;MAG Parameter Summary

43
QUICK START CHART FOR MIG/MAG WELDING
MAG
• SYNERGY OFF
• SYNERGY ON
• PULSED
• Right -
Voltage ( VOLT)
• Left - Wire Speed (m/min)
• Electronic Inductance
SYNERGY OFF
SYNERGY ON
PULSED
MODE :2T/4T/Spot
Spot Time : (0-10 sec)
Slope : (0-1.50 sec)
BBT: (1-10)
IND.: (0-11)
POST GAS: (0 – 5 Sec.)
CRATER FILL (30-100%)
• Right - Thickness (mm)
• Left - Wire Balance (±40%)
• Right - Thickness (mm)
• SX - Wire Balance (±40%)
• Preset Welding Programs
Save & Recall of operator’s Setups
