INSTALLING THE CYCLOCOMPUTER ON YOUR BIKE -
PRO SCIO 3.3
MOUNTING THE WIRED CADENCE SENSOR
(continued)
4. Route the sensor wire forward and under the bottom bracket and
along the bottom of the down tube securing it occasionally with
tape. Once you are near the head tube the sensor wire should be
wrapped around the front or rear derailleur cable housing and the
around the front brake cable housing.
Wrap any excess wire around the front brake cable housing. Use
electrical tape to secure the cable in place if necessary. When you
are done you should have just enough wire left to connect to the
receiver unit’s mounting point.
#!54)/.Make sure you leave enough slack in the sensor wire so the
handle bars can turn fully from side to side.
4
