INSTALLING THE CYCLOCOMPUTER ON YOUR BIKE
INSTALLING THE WIRELESS FORK TRANSMITTER
The PRO Scio 3.3, 3.5 and 4.1 receive speed and distance from a wireless transmitter
mounted to the front fork.
1. Attach the wireless front wheel sensor and rubber mounting
pad to the front of the left fork blade using the zip-ties
provided so the battery cap is pointing downward. Snug up
the zip-ties but do not fully tighten them. The sensor should
be mounted as high on the fork blade as possible. The range
of the transmitter is approximately 18in (46cm). Mounting
it high on the fork will assure good signal reception. Other
mounting locations may work, but we feel this is the best
location for most applications.
2. Attach the spoke magnet to a spoke on the same side of
the wheel as the sensor. Tighten the attachment screw just
enough to hold the magnet in place but loose enough so that
it is still movable.
