INSTALLING THE CYCLOCOMPUTER ON YOUR BIKE
MOUNTING THE HANDLEBAR/STEM BRACKET
Place the Cyclecomputer unit into the mounting bracket and turn
clockwise until the unit snaps into place.
./4%When mounting the unit on the stem, you must first remove the
4 screws on the back of the mounting bracket and rotate it 90 degees.
Replace the screws - do not overtighten. The unit is now properly aligned
for mounting on the stem.
2. Place the mounting bracket in the desired position on handle bars
or stem.
3. Thread the zip-ties provided through the holes on one side of the
mounting sleeve and around the handlebar or stem. Once the unit
is positioned correctly, secure the zip-ties and trim off the excess
ends.
