OPERATION
PEAK 86037220 02/12/07
3-1
TECHNICAL SPECIFICATIONS
ITEM DIMENSION/CAPACITY
Engine speed 2850 rpm (high speed) Water Pump ON
1200 rpm (idle speed) Water Pump OFF.
Water pump rpm 1750 rpm
Vacuum pump rpm 3250 rpm
Water flow rate 3.5 GPM (maximum)
Water pump pressure (low pressure) 1000 PSI (maximum)
Vacuum relief valve 13” Hg
Waste tank capacity 60 gallons
Console weight 770 lbs.
Console weight (with waste tank & waste tank
accessories) 990 lbs.
TORQUE VALUES
Engine hub 300 inch lbs 25 foot/lbs
Vacuum pump hub 300 inch/lbs 25 foot/lbs
Front engine pulley 216 inch/lbs 18 foot/lbs
Water pump clutch shaft bolt 300 inch/lbs 25 foot/lbs
JET SIZING:
Recommended floor tool tip sizing not exceed a total of “.045”. Using larger jet sizes on your cleaning unit may
reduce cleaning temperatures.
Example: Tri-jet wand uses three 95015 jets (95° spray angle w/ 015 orifice).
015 X 3 = 045
Upholstery tool jet size: 80015
Stair tool jet size: 9502
