FRAME
PEAK 86037220 01/12/08
5-2
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM NOTES:
1 86282850 790635 2 TRIM, SEAL 5/8” BULB, 1.5
2 86282840 790634 2 TRIM, SEAL 5/8” BULB, 16
3 86043940 791056 1 ASSY, RAD CLOSEOUT, PEAK NEW
1000141381
WAS 61410
4 86274000 70069 4 SCR, 3/8-16 X 3 HHCS GR5
5 86279510 87171 8 WASHER, 3/8 FLAT
6 86191570 01-000259 7 RECPT SNAPIN 1/4 TURNFAST
7 86055900 790985 1 PNL, REAR HOOD MTG, PEAK
1000141381
WAS 790393
8 86005770 57119 4 NUT, 3/8-16 HEX NYLOCK
9 86273180 00-000078 8 SCR, 1/4-20 X 1” HXHD BRD8
10 86273330 00-000286 4 SCR, CAP 1/4-20 X 2.75 HXHD
11 86270330 02-000066 15 FLATWASHER, 1/4
12 86233390 80887 2 CLAMP, 7/8 DIA “P” CUSHIONED
13 86043840 790793 1 ASSY, FRAME
1000141381
WAS 790099
14 86010780 87162 8 WASHER, 1/4 SPLIT LOCK
15 86046170 790961 1 BRKT, FUEL/LEFT HOOD MTG
1000141381
WAS 790573
16 86054600 790010 1 PNL, BELT GUARD, REAR
17 86057160 790437 1 BRKT, 1/8 ALUM COUPLER
18 86179620 790487 1 DIPSTICK, CAT PUMP OIL 5CP
19 86176170 64-950383 1 CABLE, RETAIN VAC PLG 800
20 86177210 03-000051 1 CLMP, CABL 7/16 ID 1/4 BLT
10010770000119
21 86005680 57047 2 NUT, 1/4-20 HEX NYLOCK
