ENGINE
PEAK 86037220 11/13/08
5-14
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86136270 57053 2 NUT, M6 HEX ZINC PLATED
2 86279140 87085 2 WASHER, M6 SPLIT LOCK DIN127B
3 86193580 790614 2 STUD. 6MM X 95MM
4 86182720 790622 2 GSKT, THERM, KHLR, 25HP
5 86184890 790594 1 HOSE, THERM ADPT TO HELICOIL
6 86177310 03-000248 6 CLAMP, HOSE #16 1-1/2 MIN 1-3/4
7 86181430 12-800367 1 FTG, BRB 1P X 1H BR
8 86173560 790581 1 ADAPTER, THERMOSTAT TOP AEGIS
9 86180880 790532 1 ENG, 25 HP KOHLER, AEGIS
10 86191260 790584 1 PULLEY, AEGIS WTR PMP
- OPEN - - -
12 86174950 44-802217 1 BELT, AX43 GOODYEAR MATCH
13 86006760 70305 2 SCR, 5/16-18 X 3/4 HHCS
14 86051510 790396 1 PLT, ENG MTG, PEAK
15 86010790 87163 2 WASHER, 3/8 SPLIT LOCK
16 86275190 70377 2 SCR, 3/8-16 X 1.25 HHCS SS
17 86005770 57119 6 NUT, 3/8-16 HEX NYLOCK
18 86279510 87171 20 WASHER, 3/8 FLAT
19 86274000 70069 2 SCR, 3/8-16 X 3 HHCS GR5
20 86179930 790606 3 EL, 90 DEG 1/8NPT X 1/4HB
21 86179920 790605 2 EL, 90 DEG 1/8 X 5/16HB
22 86176990 03-000065 2 CLAMP, HOSE #4 SST NOT SHOWN
23 86286150 34413 1 FILTER, AIR, KOHLER AEGIS
PRIMARY & SECONDARY
FILTER
24 86282450 790611 1 HOSE, FUEL 1/4 X 16.5”
25 86282750 790609 1 HOSE, FUEL 5/16 X 13”
26 86006820 70385 4 SCR, 3/8-16 X 2.0 HHCS GR5 PLT
27 86181620 14-806574 1 FUEL FILTER
28 86043780 790593 1 ASSY, FUEL LINE BRKT
29 86184910 790612 1 HOSEBARB, 1/8MPT X 5/16H 45 BR
30 86182730 790626 3 GSKT, EXHST, KHLR 25HP
31 86049890 790540 1 MNFLD, ENG EXH, KOHLER
32 86191060 44-802245 1 PULL, 2TB58
33 86185350 44-802214 1 HUB, P1X1-1/8
34 86174780 140976 1 BELT, GY2/BX42 HY-T BANDED V 1000161261 WAS PART 44-802307
35 86005650 57031 2 NUT, 5/16-18 HEX
36 86279130 87083 2 WASHER, 5/16 SPLIT LOCK PLTD
37 86194770 790535 1 TUBE, EXH ENG TO VAC BOX
38 86270480 48052 1 KEY, 1/4 X 1/4 X 2 1/2
39 86273440 00-000340 3 SCR, MACH 5/16-18 X 1” GR8
40 86279070 87056 2 WASHER, M6 FLAT
41 86180940 34412 1 FILTER, OIL KOHLER AEGIS
42 86174460 42-902172 1 FILTER, B & S, FUEL
-- 86181670 34417 1 FUSE, 30 AMP, ENG, AEGIS NOT SHOWN
-- 86192970 730343 2 SPARKPLUG, KOHLER RV14YC NOT SHOWN
-- 86277890 70856 1 SCREW, M5-8 X 25 MM STL, ZNC
NOT SHOWN THROTTLE
CLAMP SCR
-- 86137300 87084 1 WASHER, M5 SPLIT LOCK PLTD
NOT SHOWN THROTTLE
CLAMP LOCK WASHER
-- 86254140 791176 1 SOLENOID, KOH# 25-435-05-S NOT SHOWN
43 86194360 791178 1 THERMOSTAT, 190 DEG PEAK
44 86318100 - 1 THERMOSTAT, 205 DEGREES AEGIS
45 76177390 791166 4 CLMP, F.I., SAE 12, 1/4" HOSE
46 86177400 791167 4 CLMP, F.I., SAE 14, 5/16” HOSE 100153405
47 86180990 790556 1 FITTING, LOWER RAD HOSEO Y 100153405
- 98407380 - - KIT, THERMOSTATS, 190/205 AEGIS
