WATER PUMP
PEAK 86037220 02/12/07
5-20
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM NOTES:
1 86176520 42-809238 1 CAP, OIL FILLER
2 86189200 42-809239 1 O-RING, OIL FILL CAP
3 86195580 42-809249 1 WASHER, KEYHOLE M18
4 86024830 42-809381 1 SLINGER, BARRIER
5 86189210 42-809394 2 O-RING, BEARING CVR
6 OPEN - - -
7 86024780 42-809402 1 O-RING, CRANK CVR
8 OPEN - - -
9 86190560 42-809404 2 PLUG, VALVE
10 86024810 42-809405 1 RETAINER, SEAL
11 OPEN - - -
12 86024820 42-809407 1 RETAINER, PNLGR W/STUD
13 86190600 42-809408 1 PLUNGER
14 86192260 42-809409 1 SEAL, OIL CRANKCASE
15 86186090 42-809410 1 KIT, SEAL
ORDER 1 EACH
16 86181970 42-902380 1 GAUGE, OIL LEVEL
17 86181800 43-807063 1 GASKET, OIL GAUGE
18 86286260 66-950441 - KIT, VLV CAT 3CP1140, 33258
ORDER 1 EACH TO
REPLACE ALL VALVES
