VAC/HEAT EXCHANGER WITH SILENCER
PEAK 86037220 02/12/07
5-22
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86279510 87171 15 WASHER, 3/8 FLAT
2 86181840 790039 1 GSKET, VAC HE BOX TO MUFFLER
3 86005770 57119 7 NUT, 3/8-16 HEX NYLOCK
4 86059270 790616 1 VAC MUFFLER
5 OPEN - - -
6 86274910 70325 1 SCR, 5/16-18 X 1.25 HHCS GR5PLT
7 86270330 02-000066 22 FLATWASHER, 1/4
8 86010780 87162 22 WASHER, 1/4 SPLIT LOCK PLTD
9 86273180 00-000078 18 SCR, 1/4-20 X 1” HXHD GRD8
10 86051550 790578 1 PLT, BLNK CVR VAC HE
11 86043150 790388 1 ASSEMBLY, HEATER CORE SS
12 86177700 12-800282 2 CONN, 3/8P X 1/2T BR
13 86187210 790038 2 MANIFOLD, HEATER CORE
14 86190520 11-800224 4 PLUG, 3/8 SOCHD BR
15 86177260 03-000111 1 CLMP, HOSE #10 9/16 MIN
16 86181330 12-800161 1 FTTG, BRB 3/8P X 1/2H BR
17 86177060 03-000246 1 CLAMP, HOSE #8 SST
18 86181400 12-800345 1 FTTG, BRB 3/8P X 5/8H BR
19 86180220 11-800276 2 ELL, 3/8 BR
20 86182190 36238 1 GROM, 1/2IDX1-14OD 1/8G 5/16W
21 86051220 620023 1 PLT, HEATER CORE CVR, STL
22 86051230 620024 1
PLT, HEATER CORE CVR FRONT,
STL
23 86181850 790050 3 GASKET, VAC HE CVR
24 86189720 790343 2 PAD, BTM VAC HTR CORE
25 86189730 790423 2 PAD, REAR VAC HTR CORE
26 86272970 00-000064 14 RIV, 1/8 X 3/8 ALUM
27 86274000 70069 4 SCR, 3/8-16 X 3 HHCS GR5
28 86029780 790505 1 CORE, HTR COPPER
INCLUDES 20 & 22
29 86051410 790051 6 PLT, NUT-VAC HE HSG
30 86049180 790064 1 HSG, VAC HE
31 86051490 790329 1 PLT, LOWER EXHAUST
32 86184410 730420 1 SEAL, 5.813 DIA., GRAPH, BRAID SQ
1000161005 WAS 790330
33 86051480 790328 1 PLT, UPPER EXHAUST
34 86051460 790121 1 PLT, VAC MUFFLER MTG
35 OPEN - - -
36 86278830 02-000143 2 WASHER, 5/16 FLAT PLTD
37 86005750 57113 1 NUT, 5/16-18 HEX NYLOCK
38 86277680 70937 4 SCR, 1/4-20 X 1 1/4 HXHD GR8
To Next Page
