SOLUTION MANIFOLD
PEAK 86037220 05/22/08
5-26
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM NOTES:
1 86180410 12-800225 1 ELL, 3/8P X 1/2T BR
2 86175920 11-800118 1 BUSH, 3/8 X 1/8 BR
3 86192490 34-903019 1 SENDER, TEMP 140-320 DEG
4 86180420 12-800261 1 ELL, 1/8P X 1/4T 45 DEG
5 86187220 790324 1 MANIFOLD, SOLUTION
6 86180420 12-800261 1 ELL, 1/8P X 1/4T 45 DEG
1000141381
WAS 11-800206
7 86177660 12-800065 1 CONN, 1/8P X 1/4T
8 86274750 70270 4 SR, 1/4-20 X 3/4 HHCS PLTD
9 86010780 87162 4 WASHER, 1/4 SPLIT LOCK
10 86190520 11-800224 1 PLUG, 3/8 SOCHD BR
11 86272720 11-800345 1 PLG, 1/4 SOCHD BRASS
12 86247680 56015 1 NIPPLE, 1/4 HEX
13 86002450 22015 1 COUPLER, 1/4 QD
14 86192210 14-806549 1 SCREEEN, CHECK VALVE
15 86195030 15-808094 1 VALVE, CHECK
16 86192210 14-806549 1 SCREEN, CHECK VALVE
17 86189260 43-810053 1 O-RING
18 86189230 43-810008 1 O-RING
19 86192390 16-808223 1 SEAT, CHK VLV ASSY
20 86194250 16-808225 1 TEFLON SEAT
21 86190910 16-808226 1 POPPET, CHK VLV ASSY
22 86193260 16-808224 1 SPRING
23 86189270 43-810079 1 O-RING, 7/8 ID 1-1/16 OD
24 86176350 16-808222 1 CAP
