Prochem PEAK - Page 81

WAND-TITANIUM SIX JET-OPTIONAL
PEAK 86037220 12/27/06
5-42
REF PART NO. PRV NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 86273310 00-000282 SCR, CAP 1/4-20 X 1 1/4 SOC
2 86192030 00-000317 SCR, CAP 10-32 X 1 1/4 SOCH
3 86006680 70228 SCR, 10-32 X 1/4 PPHMS SS
4 86270990 57090 NUT, 10-32 HEX NYLOCK SS
5 86264910 04-000093 TIE, CABLE 13”
- OPEN - -
7 86184270 10-805504 HOSE, 3/16 X 44-1/2
8 86247680 56015 NIPPLE, 1/4 HEX
9 86190180 11-800206 PLUG, 1/8 SOCHD BR
10 86177650 12-800060 CONN, 1/4P X 1/4T BR
11 86177710 12-800322 CONN, 1/8P X 1/4T COMP BR
12 86005580 56012 NIPPLE, 1/4 FPT QD
13 86193490 14-806512 STRAINER, JET 50 MESH
14 86194450 17-803018 TIP, SPRAY 9501 X 1/8P SST
15 86195570 17-803006 WASHER, NYLON
16 86177860 17-803010 CONN, 1/4P X 11/16-16M
17 86177870 17-803036 CONN, 1/4FP X 11/16-16F BR
18 86194580 17-803078 TIP, SPRAY 8001 SST 1/8 VJET
19 86194650 52-501619 TRIGGER, WD VALVE
20 86174680 52-502008BK BODY, WD HDL, 2” TB, BK
21 86198180 52-502009 HOLD DN-WD HDL 2” TUBE
22 86187610 52-502057 MANFOLD, LEFT
23 75187620 52-502058 MANIFOLD, RIGHT
24 86174060 56-502548 ASSY, MNFLD S-BEND
25 86285440 56-502534 WD & HD, TITANIUM
26 86174120 61-950496 ASSY, EXTRACTOR VALVE
27 86193360 16-808189 STEM, EXTRACTOR VALVE
28 86193200 16-808190 SPRING, EXTRACTOR VALVE
29 86192410 16-808228 SEAT, EXTRACTOR VALVE
30 86183160 16-808229 HLDR, VLV STEM-EXTRACTOR VL
31 86189510 43-810062 O-RING, .114 ID .254OD
32 86189520 43-810063 O-RING, .551ID .691OD
33 86174500 43-810064 BACK-UP, .250DIA
34 86174630 52-501590 BDY, EXTRACTOR VLV
35 86179250 48-941462 DEC, WD HD TITANIUM
- OPEN - -
