WAND-QUAD JET-OPTIONAL
PEAK 86037220 02/12/07
5-44
REF PART NO. PRV NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
-
86285570 89238 WAND, TM, QJW (95015) PC
COMPLETE
-
86285580 89239 WAND, TM, QJW (9502) PC
COMPLETE
-
86285560 89237 WAND, TM QJW (9501) PC
COMPLETE
-
86285540 89235 WAND, TM, QJW, (9501) NO DECAL
COMPLETE
1
86005580 56012 NIPPLE, 1/4 FPT QD
2
86177860 17-803010 CONN, 1/4P X 11/16-16M
3
86195570 17-803006 WASHER, NYLON
4
86193490 14-806512 STRAINER, JET 50 MESH
5
86177870 17-803036 CONN, 1/4FP,11/16-16R BR
6
86247680 56015 NIPPLE, 1/4 HEX
7
86280020 09-805359 SLEEVE, WD HDL 9.5
8
86194650 52-501619 TRIGGER, WD VLV
9
86192030 00-000317 SCR, CAP 10-32X 1-1/4 SOCH
10
86270990 57090 NUT, 10-32 HEX NYLOCK SS
11
86174120 61-950496 ASSY, EXTRCTR VLV
12
86177650 12-800060 CONN, 1/4P X 1/4T BR
13
86183970 10-805387 HOSE, 3/16 X 43-1/2 (1/8P X 1/4)
14
86265730 04-000053 TIE, CABLE 8” WHT
15
86273310 00-000282 SCR, CAP 1/4-20 X 1-1/4 SOC
16
86198160 52-501569 HOLD DOWN, WD HDL
17
86182840 791150 HANDLE GRIP ASSEMBLY 1.75”
18
OPEN -
-
19
86190180 11-800206 PLUG, 1/8 SOCHD BR
20
86043300 56-501966 ASSY, L S-BEND MNFLD
21
86273450 00-000347 SCR, CAP 10-24 X1/4 SOCHD
22
86279470 87165 WASHER, #10 SPLIT LOCK
23
86194400 17-803001 TIP, SPRY 95015X1/8P SST
89238
23A
86194410 17-803002 TIP, SPRY 9502X1/8P SST
89239
23B 86194450 17-803018 TIP, SPRY 9501X1/8P SST
89237
89235 (NO DECAL)
24
86043310 56-501986 ASSY, RT S-BEND MNFLD
25
86177710 12-800322 CONN, 1/8PX1/4T COMP BR
26
86174030 56-501967 ASSY, S-BEND MNFLD
27
86183160 16-808229 HOLDER, VLV STEM-EXTRCTR VL
28
86189520 43-810063 O-RING, .551 ID .691 OD
29
86192410 16-808228 SEAT, EXTRCTR VLV
30
86193360 16-808189 STEM, EXTRCTR VLV
31
86174500 43-810064 BACK-UP, .250 DIA
32
86189510 43-810062 O-RING, .144 ID .254 OD
33
86193200 16-808190 SPRING, EXTRCTR VLV
34
86174630 52-501590 BODY, EXTRCTR VLV
-
86179020 48-941186 DECAL, WD HD (CAST SS)
NOT SHOWN
- 86186160
66-808169
KIT, REP-WD VLV
NOT SHOWN
INCLUDES PARTS
27-29 & 31-33
