WAND- TRI JET-OPTIONAL
PEAK 86037220 02/12/07
5-46
REF PART NO. PRV NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
-
86285520
89233 WAND, TJW (9502) PC COMPLETE
-
86285510
89232 WAND, TJW, (95015) CUBXL COMPLETE
-
86285530
89234 WAND, TJW, (9503) PC COMPLETE
1
86005580
56012 NIPPLE, 1/4 FPT QD
2
86177860
17-803010 CONN, 1/4P X 11/16-16M
3
86195570
17-803006 WASHER, NYLON
4
86193490
14-806512 STRAINER, JET 50MESH
5
86177870
17-803036 CONN, 1/4FP,11/16-16R BR
6
86247680
56015 NIPPLE, 1/4 HEX
7
86280020
09-805359 SLEEVE, WD HDL 9.5
8
86194650
52-501619 TRIGGER, WD VLV
9
86192030
00-000317 SCR, CAP 10-32X 1-1/4 SOCH
10
86270990
57090 NUT, 10-32 HEX NYLOCK SS
11
86174120
61-950496 ASSY, EXTRCTR VLV
12
86177650
12-800060 CONN, 1/4P X 1/4T BR
13
86183970
10-805253 HOSE, 3/16X49 (1/8P X 1/4FT)
14
86265730
04-000053 TIE, CABLE 8” WHT
15
86273310
00-000282 SCR, CAP 1/4-20 X 1-1/4 SOC
16
86198160
52-501569 HOLD DOWN, WD HDL
17 86182840 791150 HANDLE GRIP ASSEMBLY 1.75
18
OPEN
- -
19
86194410
17-803002 TIP, SPRY 9502X1/8P SST 89233
19A
86194400
17-803001 TIP, SPRY 9501X1/8P SST 89232
19B
86194520
17-803046 TIP, SPRY 9503X1/8P SST 89234
20
86274290
70162 SCR, 10-32 X 3/8 PPHMS SS
21
86279470
87165 WASHER, #10 SPLIT LOCK
22
86270800
57014 NUT, 10-32 HEX SS
23
86187700
56-501739 MANIFOLD, WD TRI-JET
24 86190180 11-800206 PLUG, 1/8 SOCHD BR
25 86183160 16-808229
HOLDER, VLV STEM-EXTRCTR
VL
26
86189520
43-810063 O-RING, .551 ID .691 OD
27
86192410
16-808228 SEAT, EXTRCTR VLV
28
86193360
16-808189 STEM, EXTRCT VLV
29
86174500
43-810064 BACK-UP, .250DIA
30
86189510
43-810062 O-RING, .114ID .254OD
31
86193200
16-808190 SPRING, EXTRCTR VLV
32
86179020
52-501590 BODY, EXTRCTR VLV
-
86179020
48-941166 DECAL, WD HD NOT SHOWN
- 86186160 66-808169 KIT, REP-WD VLV
NOT SHOWN
INCLUDES PARTS
25-27 & 29-31
