Prochem PEAK - Page 87

STAIR TOOL-OPTIONAL
PEAK 86037220 02/12/07
5-48
REF PART NO. PRV NO. DESCRIPTION
SERIAL NO.
FROM NOTES:
-
86285350
78519 TL, STAIR, LNG, TM DJ (80015) COMPLETE
-
86285290
78521 TL, STAIR, SHT, TM (80015) COMPLETE
1A
OPEN
- -
1B
OPEN
- -
2
86198080
52-501576 BODY, WD HDL PORT
3
86198170
52-501577 HOLD DOWN, WD HDL PORT
4
86265730
04-000053 TIE, CABLE 8” WHT
5
86183710
10-805330 HOSE, 3/16X13-3/4 (1/8PX1/4)
5A
86184000
10-805397 HOSE, 3/16X7-1/2 (1/8P X 1/4F)
6
86194410
17-803002 TIP, SPRY 9502X1/8P SST
7
86273310
00-000282 SCR, CAP 1/4-20 X 1-1/4 SOC
8
86177650
12-800060 CONN, 1/4P X 1/4T BR
9
86192030
00-000317 SCR, CAP 10-32X1-1/4 SOCH
10
86270990
57090 NUT, 10-32 HEX NYLOCK SS
11
86174120
61-950496 ASSY, EXTRCTR VLV
12
86247680
56015 NIPPLE, 1/4 HEX
13
86005580
56012 NIPPLE, 1/4 FPT QD
14
86194650
52-501619 TRIGGER, WD VLV
15
86280020
09-805359 SLEEVE, WD HDL 9.5
15A
86040950
09-805504 SLEEVE, STAIR TL HDL 7-1/8
16
86183160
16-808229 HOLDER, VLV STEM-EXTRCTR VL
17
86189520
43-810063 O-RING, .551 ID .691 OD
18
86192410
16-808228 SEAT, EXTRCTR VLV
19
86193360
16-808189 STEM, EXTRCTR VLV
20
86174500
43-810064 BACK-UP, .250DIA
21
86189510
43-810062 O-RING, .114 ID .254 OD
22
86193200
16-808190 SPRING, EXTRCTR VLV
23
86174630
52-501590 BODY, EXTRCTR VLV
-
86178970
48-941163 DECAL, STAIR TL NOT SHOWN
-
86186160
66-808169 KIT, REP-WD VLV
NOT SHOWN
INCLUDES PARTS
16-19 & 20-22
