UPHOLSTERY TOOL-OPTIONAL
PEAK 86037220 02/12/07
5-50
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
-
86285260
78513 1
TL, UPHOLST, PC (80015)
COMPLETE
1
86280240
09-805131 2
HOSE, VAC 1-1/4X10’ BLU
2
86178660
08-805243 1
CUFF, SWIV 1-1/4HX1-1/4T
3
86184670
10-805347 1
HOSE, 3/16X119-1/2 (1/8PX1/4FT)
4
86179720
13-806023 1
DSC, 1/8FC1/8FP SST
5
86178550
58-500639 1
UPHOLSTERY TL TRIGGER
6
86273370
00-000310 1
SCR, CAP 4-40 X7/32 SHCS SS
7
86193050
04-000282 1
SPRING, VAC ADJ BUTT
8
86176080
52-501624 1
BUTTON, VAC ADJ
9
86194590
52-501842 1
TOOL, UPHOLSTERY
10
86174140
61-950570 1 ASSY, UPHLST TL VLV
INCLUDES PARTS
20-26, 28, & 31- 37
11
86005580
56012 1
NIPPLE, 1/4 NPT QD
12
86177860
17-803010 1
CONN, 1/4P X 11/16-16M
13
86195570
17-803006 1
WASHER, NYLON
14
86193490
14-806512 1
STRAIRNER, JET 50MESH
15
86177870
17-803036 1
CONN, 1/4FPX11/16-16F BR
16
86188320
11-800404 1
NIP, 1/4X5 SST
17
86178520
52-501585 1
COUPLER, UPHLST TL
18
86177660
12-800065 1
CONN, 1/8P X 1/4T
19
86178630
08-805138 1
CUFF, 1 1/4H X 1 1/2T GRY
20
86183160
16-808229 1
HOLDER, VLV STEM-EXTRCTR VL
21
86189520
43-810063 1
O-RING, .551 ID .691 OD
22
86192410
16-808228 1
SEAT, EXTRCTR VLV
23
86193360
16-808189 1
STEM, EXTRCTR VLV
24
86174500
43-810064 1
BACK-UP, 250DIA
25
86189510
43-810062 1
O-RING, .144 ID .254 OD
26
86189510
16-808190 1
SPRING, EXTRCTR VLV
27
86273350
00-000306 2
SCR, 6-32 X 1 SCHD SS
28
86194500
17-803033 1
TIP, SPRY 80015X1/8P SST
29
86178540
58-500638 1
CSTG, TRIGGER CLMP
30
86273360
00-000307 2
SCR, CAP 6-32X3/8 SOCHD
31
86195210
52-501623 1
VALVE, UPHLST TL
32
86195530
52-501626 1
VALVE, ADJ-UPHLST TL VLV
33
86189460
43-810016 1
O-RING, 5/32IDX9/32OD VIT
34
86182570
43-807513 1
GASKET, UPHLST TL VLV
35
86183770
10-805348 1
HOSE, 3/16X6-1/2 (1/8P BS)
36
86179740
13-806030 1
D SC, 1/8MX1/8FP SST
37
86192070
00-000408 1
SCR, SET 3-32 X 1/4 SOCHD
-
86178980
48-941164 1
DECAL, UPHLST TL
NOT SHOWN
- 86186160
66-808169 1 KIT, REPAIR-WAND VLV
NOT SHOWN
INCLUDES PARTS 20-22 &
24-26
To Next Page
