SHELF ASSEMBLY-OPTIONAL
PEAK 86037220 05/22/08
5-52
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM NOTES:
- 86285410 65-950392 1 VAN STORAGE UNIT COMPLETE
1 86192680 56-501921 1 SHELF, LWR
2 86270330 02-000066 20 FLATWASHER, 1/4
3 86010780 87162 20 WASHER, 1/4 SPLIT LOCK
4 86274760 70271 20 SCR, 1/4-20 X 1/2 HHCS PLTD
5 86274750 70270 4 SCR, 1/4-20 X 3/4 HHCS PLTD
6 86175710 50-501840 1 BRKT, ADJUST MTG SLOT
7 86175730 56-502067 1 BRKT, ADJUST MTF HLDR
8 86198090 56-501942 1 BRKT, SHELF MOUNTING
9 86285120 41460 1 HOLDER, STAIR TOOL
10 86270620 01-000105 4 LOCK NUT, 1/4-20 HXHD
11 86024890 56-501922 2 PANEL, SHLF END
12 86278840 50-501749 2 WASHER, NYLON
13 86021920 56-501920 1 DRAWER, SHELF GRAY
14 86186850 46-802506 1 LATCH, ADJ GRIP
15 86183180 50-501755 1 HOLDER, UP TL HOSE
16 86183170 50-501754 1 HOLDER, UPHST TL
17 86179350 48-941152 1 DECAL, PROCHEM
- 86162440 66-945424 1 KIT, ADJ BRKT.
INCLUDES
PARTS 6,7 &
MOUNTING
HARDWARE
