HOSE REEL-OPTIONAL
PEAK 86037220 02/12/07
5-60
REF PART NO. PRV NO. QTY DESCRIPTION
SERIAL NO.
FROM NOTES:
1
86191620
56-501962 1 REEL, VACUUM HOSE GRAY
2
86177270
03-000124 2 CLAMP, MFLR 1-3/4
3
86175990
52-501685 2 BUSHING, HOSE REEL
4
86174560
56-501960 1 BASE, HOSE RL (250’)
5
86175740
56-502207 1 BRKT, LOCKOUT HOSE REEL
6
86186870
61-950854 1 LATCH ASSEMBLY
7
86270330
02-000066 2 FLATWASHER, 1/4
8
86010780
87162 2 WASHER, 1/4 SLPIT LOCK
9
86274750
70270 2 SCR, 1/4-20 X 3/4 HHCS PLTD
10
86005650
57031 2 NUT, 5/16-18 HEX
11
86191820
56-501968 1 REEL, HP HOSE GRAY
12
86174740
45-802138 2 BEARING HOSE REEL
13
86278830
02-000143 4 FLATWASHER, 5/16
14
86279130
87083 4 WASHER, 5/16 SPLIT LOCK PLTD
15
86006750
70302 4 SCR, 5/16-18 X 1” HHCSGR5PLT
16
86181030
44-802122 4 FLANGE, 47MST
17
86174730
56-501961 1 BODY, HP HOSE GRAY
18
86277830
00-000072 10 SCR, 3/8-16 X 2” HXHD
19
86190170
50-500511 1 PLATE, INSTALL MT
20
86279510
87171 10 WASHER, 3/8 FLAT
21
86005770
57119 10 NUT, 3/8-16 HEX NYLOCK
22
86189850
55-501789 1 PIN, LOCK HOSE REEL
23
86175700
50-501812 1 BRKT, HOSE REEL LOCK
24
86193240
04-000302 1 SPRING, LOCK-LOCK PIN ASSY
25
86177190
04-000303 1 CLIP, RETAINER-LOCK PIN ASSY
