OPERATION
PERFORMER 980060 07/05/03
3-20
OPERATION
Once you have completed steps 1 through 9,
proceed with the cleaning operation. Your unit
should be in the correct throttle position for your
cleaning or extracting. A float switch located inside
the waste tank will automatically shut down the unit
when it reaches its full capacity. When this occurs,
empty the waste tank before continuing.
EXHAUST DIVERTER VALVE
The automatic exhaust diverter directs exhaust
through either:
a) the engine exhaust HEAT EXCHANGER
for high temperature cleaning, or
b) through the exhaust MUFFLER for
cooler temperature, such as flood
restoration.
Set temperature control to desired temperature for
cleaning operations. The auto diverter will
automatically switch between A & B to maintain
temperature. Set temperature control to 50°F for
flood extraction.
CLEANING
Observe the following guidelines, while cleaning:
1. Before proceeding make sure the nozzles are
functioning properly.
a) To check, hold the wand about one foot
above the surface to be cleaned and open
the wand valve. A full spray should be
observed from the cleaning nozzles.
b) If the nozzles are not showing a full spray
pattern, adjust nozzles for proper pattern,
clean, or replace nozzles, if required.
2. Normally, chemical is applied on the push stroke
of the wand when cleaning, and vacuuming is
done on the pull stroke. For heavily soiled
carpets the wand may be used in a scrubbing
manner, applying chemical in both push and pull
strokes. Always finish up an area with a vacuum
pull stroke.
3. When cleaning, keep the working opening
(mouth) flat on the surface being cleaned. Keep
the wand moving when the valve is open.
4. The unit will automatically shut-down when the
waste tank is full. This will prevent water being
drawn into the vacuum pump. If shut-down
occurs, empty the waste tank before proceeding.
NEVER dispose of waste in storm drains,
waterways, or onto the ground. Always dispose
of waste in accordance with Local, State, and
Federal laws.
UPHOLSTERY CLEANING
Upholstery Tool, Part #78513
1. Set temperature as desired and slow down
engine speed to minimize excess heat.
2. Use one (1) "80015" spray tip in either tool.
3. Pressure adjustment below 300 PSI should be
made at the tool itself, by using the adjusting
knob located on the valve.
