WATER PUMP ASSEMBLY
PERFORMER 980060 07/22/03
5-18
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 41-809149 PUMP, WTR, CAT 5CP2150
2 87171 WASHER, 3/8 FLAT
3 87163 WASHER, 3/8 SPLIT LOCK
4 57111 NUT, 3/8-16 HEX
5 12-800060 CONN, 1/4P X 1/4T BR
6 10-805316 HOSE, 3/16 X 5 (1/4FT BS) MET
7 12-800029 PLUG, 1/4T BR
8 70461 SCR, 3/8-16 X 3.5 HHTB GR5 PLTD
9 12-800225 ELL, 3/8PX1/2T BR
10 02-000143 FLATWASHER, 5/16
11 87083 WASHER, 5/16 SPLIT LOCK PLTD
12 70262 SCR, M8 X 20 HHMS PLTD
13 31-900185 CONN, BULLET M (.156)
14 44-802314 BELT, AX39 GOODYEAR MATCH
15 36-900141 CLUTCH, ELEC WTR PMP CAT
16 56-501995 BRKT, PMP ADJ
17 11-800224 PLUG, 3/8 SOCHD BR
18 52-800315 ELL, ST 1/2 (CAT PMP)
19 12-800278 FTTG, BTB 1/2P X 3/4P BR
20 03-000113 CLAMP, HOSE #12 SST
21 09-805435 HOSE, WATER .75 X 33.0
22 52-809123 RETAIN, VALVE STRING
23 52-809125 ADPT, CAT CHEM PMP
24 41-809158 PUMP, CHEM (O-RING CAP)
25 12-800040 ELL, 1/8P X 1/4T BR
26 10-805278 HOSE, 3/16 X54 (1/4FT BS) MET
27 11-800014 ELL, STREET 1/8 BR
28 12-800093 FTTG, BRB 1/8P X 5/16H
29 03-000065 CLAMP, HOSE #4 SST
30 09-805088 HOSE, BRD 5/16X64
31 10-805359 HOSE, HP 3/8 X 42 (1/2FT BS)
32 11-800069 PLUG, 1/2 SOCHD BR
33 48008 KEY, 3/16 X 17.75
- 05-008016 OIL, CAT-WTR PMP NOT SHOWN
