VACUUM EXHAUST HEAT EXCHANGER
AND SILENCER - PERFORMER 405
PERFORMER 980060 07/01/02
5-26
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 00-000210 SCR, 1/4-20 X 3/4, SOCHD
2 87162 WASHER, 1/4 SPLIT LOCK
3 56-501955 ASSY, EXH OUTL
4 03-000081 CLMP, MFLR 1-1/2 ZNC PL
5 09-805433 HOSE, INT VAC 3.25 X 2.5
6 03-000250 CLAMP, HOSE #60 3.3125/4.5 SST
7 56-501938 HSG, VAC HE , BRU2
8 02-000066 FLATWASHER, 1/4
9 70720 SCR, 10 X 3/8 PPHST TYPE B
10 57-520089 MUFFLER, VAC
11 09-805425 HOSE, INT VAC 3.5 X 5.0 BLK
12 00-000078 SCR, 1/4-20 X 1’ HXHD GRD8
13 43-807108 GASKET, VAC HE INLET
14 58-700027 PAD, VAC HE CORE
15 43-807081 GASKET, VAC HE CORE
16 09-805288 HOSE, WTR 5/8X27
17 03-000246 CLAMP, HOSE #8 SST
18 09-805343 HOSE, WTR 5/8X17
19 09-805372 HOSE, WTR 5/8X6-1/2
20 61-950695 SUB-ASSY, VAC HE CVR
21 61-950696 VAC HE CORE
