HELI-COIL HEAT EXCHANGER ASSEMBLY
PERFORMER 980060 12/16/03
5-
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 57-520073 HE, HELI-COIL INCLUDES PARTS 2-9
2 52-501583 SHELL, HE 800A, 800RD
3 70340 SCR, 1/2-13 X 1.25 HHCS GR5PLT
4 57-520033 COIL, HE
5 43-807051 GSKT, MNFLD HE
6 43-807049 GSKT, HE
7 52-000124 NUT, 1-3/4-12HXHD HE
8 56-501505 RNG, LOCK, MNFLD, HE
9 52-501631 PL, CVR HE BC
10 00-000363 SCR, CAP 5/8-11 X 2 HXHD
11 02-000232 LOCK WASHER, 5/8
12 56-502005 BRKT, RT HOOD
13 02-000088 FLAT WASHER, 5/8 HVY
14 50-501686 CLIP, SPRING
15 04-000287 SPRING, DVTR RET
16 790648 HOSE, THERM ADAPT TO HELICOIL
17 03-000248 CLMP, HOSE #16 1-1/2 MIN 1-3/4
18 10-805375 HOSE, HP 3/8 X 19 (1/2FT BS)
19 10-805274 HOSE, HP 3/8 X 26 (1/2FT BS)
20 12-800326 ELL, 3/4P X 1/2T BR
21 52-501627 INLET, HE
22 790647 HOSE, ENGINE TO Y ADAPTER
23 31016 ELBOW, 1/4NPT STREET
24 15-808073 COCK, DRN 1/4P X 1/4 HOSE ELL
25 00-000015 SCR, DRV .098 X 3/16
- 66-945200 KIT, HELI-COIL W/GASKETS NOT SHOWN
