ENGINE EXHAUST HEAT EXCHANGER
PERFORMER 980060 07/01/02
5-30
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
- 61-950628 ASSY, CAT HE
INCLUDES PARTS 1-4,
5-14
- 61-950582 ASSY, HE NON-CAT INCLUDES PARTS 4A-14
1 01-000271 NUT, 1/4-20 HXHD BR
2 52-501643 SHIELD, CAT HE
3 58-700028 PAD, CAT HT SHLD
4 56-501759 COVER, CAT HE END BC CATALYTIC
4A 58-500791 CSTG, CAT CONV W/TUBE TM NON-CATALYTIC
5 43-807086 GSKT, EXH FLG BC
6 57-520074 ASSY, COIL MT&CSG BC
7 57006 NUT, 1/4-20 HEX
8 02-000044 LOCKWASHER, 1/4 SST
9 70015 SCR, 1/4-20 X 3/4 HHCS SS
10 52-501654 NUT, ADAPT BUSH
11 64-950546 ASSY, HE TEMP SHTOFF
12 35-900184 SENSOR, TEMP 285DEG
13 52-501671 FTTG, TEMP SENS ADPT TM
14 12-800171 ELL, 1/2P X 1/2T BR
15 10-805376 HOSE, 1/2 X 14-1/2 (1/2FT BS)
16 02-000274 LOCKWASHER, 5/16 (ALLEN SCREW)
17 00-000315 SCR, CAP 5/16-18 X 7/8 SOCHD
18 42-902212 ONAN GSKT, EXH #154-2747
19 10-805274 HOSE, HP 3/8 X 26 (1/2FT BS)
20 02-000066 FLATWASHER, 1/4
21 87162 WASHER, 1/4 SPLIT LOCK PLTD
22 00-000078 SCR, 1/4 X 1” HXH D GRD8
- 66-945532 KIT, EXH HE CORE
NOT SHOWN (INCLUDES
PARTS 3,5,6 AND 18)
