BYPASS MANIFOLD
PERFORMER 980060 07/01/02
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 10-805357 HOSE, 3/16X38 (1/4FT BS) MET
2 12-800040 ELL, 1/8P X 1/4T BR
3 56-501906 ASSY, BRKT, BYPASS MTG
4 12-800065 CONN, 1/8P X 1/4T
5 10-805130 HOSE, 3/16 X 13-1/2 (1/4FT BS)
6 87162 WASHER, 1/4 SPLIT LOCK
7 00-000132 SCR, 1/4-20 X 1-1/2 HXHD
8 15-808112 ASSY, BYPASS MNFLD (CATALYTIC)
8A 15-808111 ASSY, BYPASS MANIFOLD (NON-CATALYTIC)
9 10-805130 HOSE, 3/16 X 13-1/2 (1/4FT BS) (CATALYTIC)
9A 10-805393 HOSE, 3/16X14-1/4 (1/4FT BS) (NON-CATALYTIC)
10 70105 SCR, 1/4-20 X 1.75 HHCS PLTD
11 02-000066 FLATWASHER, 1/4
12 57006 NUT, 1/4-20 HEX
13 52-501659 MANIFOLD, BYPASS
14 52-501701 ORIF,BYP MNFLD (CATALYTIC)
14A 52-501665 ORIF, BYPLASS MAINFOLD (BLUE) (NON-CATALYTIC)
15 43-810053 O-RING, .676ID X .816OD
16 53-501523 CAP, CHK VALVE MANIFOLD STRNR
17 14-806552 SCREEN, BYPASS MANIFOLD
