PRESSURE REGULATOR MANIFOLD ASSEMBLY
PERFORMER 980060 11/07/02
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 790106 ACCUMULATOR
2 10-805362 HOSE, 3/16 X 16-1/2
3 12-800031 ELL, 1/4P X 1/4T BR
4 66017 PLUG, 1/4 BRASS PIPE
5 11-800224 PLUG, 3/8 SOCHD BR
6 00-000210 SCR, 1/4-20 X 3/4” SOCHD
7 10-805375 HOSE, HP 3/8 X 19 (1/2FT BS)
8 12-800347 ELL, 3/8P X 1/2T 45 DEG BR
9 10-805359 HOSE, HP 3/8 X 42 (1/2FT BS)
10 11-800368 NIP, 3/8 X CL SST
11 790067 REG, PRESS
12 09-805343 HOSE, STR 5/8 X 17
13 03-000246 CLAMP, HOSE, #8 SST
14 12-800345 FTTG, BRB 3/8P X 5/8H BR
15 11-800341 ELL, ST 3/8 45DEG BR
16 12-800225 ELL, 3/8P X 1/2T BR
17 790112 MANIFOLD, PRESS REG. 1/2” PORT
18 87162 WASHER, 1/4 SPLIT LOCK
19 16-808201 CAT#33246 KIT, O-RING REP
20 16-808200 CAT#33147 KIT, VLV, REP
