TEMPERATURE SOLENOID ASSEMBLY
PERFORMER 980060 07/05/03
REF PART NO. DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 10-805000 HOSE, 3/16 X 9 (1/4FT BS) MET
2 12-800060 CONN, 1/4P X 1/4T BR
3 15-808105 VALVE, SOLENOID 1/4F X 1/4F
4 31-900028 TERM, INS DSC 1/4M 14-16W
5 31-900027 TERM, INS DSC 1/4F 14-16W
6 10-805130 HOSE, 3/16 X 13-1/2 (1/4FT BS)
6A 10-805393 HOSE, 3/16 X 14-1/4 (1/4 FT BS)
7 12-800065 CONN, 1/8P X 1/4T
8 11-800133 TEE, 1/8 BR
9 11-800380 NIP, 1/4 X 1/8 HX SST
10 50-501744 BRKT, SOLENOID
11 87165 WASHER, #10 SPLIT LOCK
12 00-000065 SCR, 10-32 X 3/8” PBHD
13 12-800040 ELL, 1/8P X 1/4T BR
14 10-805327 HOSE, 3/16 X 10 (1/4FT BS) MET
15 02-000066 FLATWASHER, 1/4
16 87162 WASHER, 1/4 SPLIT LOCK
17 70270 SCR, 1/4-20 X 3/4 HHCS PLTD
18 15-808107 VLV, MET 1/8FP (BYPASS) RT
19 10-805363 HOSE, 3/16 X 63 1/2 (1/4FT BS)
20 12-800088 TEE, ADPT 1/8FP X 1/8P X 1/4 T
- 66-945280 KIT, BYPASS MAINT NOT SHOWN
