SPECIFICATIONS
Note: Dimensions listed are outer most points on the heater (includes control knobs and grill).
* For purposes of input adjustment.
MODEL MN100HBG ML100HBG MN100TBG ML100TBG
Ignition Piezo Piezo Piezo Piezo
Gas Type Natural Propane Natural Propane
Maximum BTU/Hr 10,000 10,000 10,000 10,000
Pressure Regulator Setting 4" W.C. 9" W.C. 4" W.C. 9" W.C.
Inlet Gas Pressure*
(inches of water)
Max 10.5" Max 14" Max 10.5" Max 14"
Min 5" Min 11" Min 5" Min 11"
Heater Dimensions (HxWxD) 21.2" x 15.79" x 6.85"
Carton Dimensions (HxWxD) 22.83" x 17.95" x 8.23"
Heater Weight 13.2 lbs 14.3 lbs
Shipping Weight 16.1 lbs 17.2 lbs
MODEL MN200HBG ML200HBG MN200TBG ML200TBG
Ignition Piezo Piezo Piezo Piezo
Gas Type Natural Propane Natural Propane
Minimum/Maximum BTU/Hr 10,000/20,000 10,000/20,000 10,000/20,000 10,000/20,000
Pressure Regulator Setting 4" W.C. 9" W.C. 4" W.C. 9" W.C.
Inlet Gas Pressure*
(inches of water)
10.5" Max. Max. 14" 10.5" Max. Max. 14"
5" Min. Min. 11" 5" Min. Min. 11"
Heater Dimensions (HxWxD) 24.1" x 18.46" x 8"
Carton Dimensions (HxWxD) 26.18" x 20.7" x 9.84"
Heater Weight 17.9 lbs 18.9 lbs
Shipping Weight 21.8 lbs 22.8 lbs
MODEL MN300HBG ML300HBG MN300TBG ML300TBG
Ignition Piezo Piezo Piezo Piezo
Gas Type Natural Propane Natural Propane
Minimum/Maximum BTU/Hr 15,000/30,000 15,000/30,000 15,000/30,000 15,000/30,000
Pressure Regulator Setting 4" W.C. 9" W.C. 4" W.C. 9" W.C.
Inlet Gas Pressure*
(inches of water)
10.5" Max. Max. 14" 10.5" Max. Max. 14"
5" Min. Min. 11" 5" Min. Min. 11"
Heater Dimensions (HxWxD) 24.1" x 25.5 x 8.46"
Carton Dimensions (HxWxD) 26.18" x 28.15" x 9.84"
Heater Weight 23.4 lbs 24.5 lbs
Shipping Weight 28 lbs 29 lbs
