Input Register (Analogue Input) Applicable Unit Type
Register Name Addr
Modicon
Address
Details
FTC4 FTC5
CAHV
master
CAHV
slave
CRHV
master
CRHV
slave
QAHV
master
EAHV
master
EAHV
slave
Return Temperature – Zone 2
(signed)
72 30073
Temperature value in ºC multiplied by 100.
(see note *)
9 9
External Water Temperature 6
(signed)
Temperature value in ºC multiplied by 100.
(see note **)
9
Return Temperature – Zone 2
73 30074
Temperature value in ºC multiplied by 100.
(see note **)
9 9
External Water Temperature 6
Temperature value in ºC multiplied by 100.
(see note **)
9
Boiler Flow Temperature
(signed)
74 30075
Temperature value in ºC multiplied by 100.
(see note *)
9 9
Boiler Flow Temperature 75 30076
Temperature value in ºC multiplied by 100.
(see note **)
9 9
Boiler Return Temperature
(signed)
76 30077
Temperature value in ºC multiplied by 100.
(see note *)
9 9
Boiler Return Temperature 77 30078
Temperature value in ºC multiplied by 100.
(see note **)
9 9
DIP Switch SW2 78 30079
Bit 0 = Switch 2-1 (0 = OFF, 1 = ON)
…
Bit 9 = Switch 2-10 (0 = OFF, 1 = ON)
9 9
Heat Pump Run Time
(hours)
79 30080
Value in hours
0 = 0 Hours … 99 = 99 Hours
9 9 9 9
Heat Pump Run Time
(hours x100)
80 30081
Value in hours multiplied by 100
0 = 0 hours
…
65535 = 6553500 hours
9 9 9 9
Heat Pump Refrigerant Address
1 Run Time (hours x100)
81 30082
Value in hours multiplied by 100
0 = 0 hours
…
65535 = 6553500 hours
9 9
Heat Pump Refrigerant Address
2 Run Time (hours x100)
82 30083
Value in hours multiplied by 100
0 = 0 hours
…
65535 = 6553500 hours
9 9
