Clip only the holding base.
Remove OB7 out of the box. Do not remove OB7 from
the foam package.
Rotate base 180 degrees.
Rotate base 180 degrees.
OB7 Collaborative Robot User Manual Version 0.6
Getting Started With OB7 / 18
Step 2: Remove OB7 keeping it attached to the foam packaging. DO NOT remove OB7 from the foam
packaging yet. Aer removing, clip ONLY the tie which is around the base of OB7. Do not clip the
other ties yet.
Step 3: Rotate the base over 180 degrees. Note that as you rotate the base, the lights on the OB7’s
joints may illuminate or ash. This is normal.
Make sure to keep OB7 in its foam package. This will make it easier to handle OB7 while
mounting it on the stand in step 4.
