15. Slide the Left Base Leg Cover (101) onto the
Base (48) as shown. Attach the Left Base Leg
Cover with three 1/2" Screws (6).
Be careful not
to overtighten the Screws.
6
48
6
6
15
16. Tighten a 1/2" Screw (6) into each side of the
Base (48) and each Base Leg Cover (101, 102).
Be careful not to overtighten the Screws.
6
102
101
48
16
101
14. Attach the ground wire on the Upright Wire (28)
to the indicated hole in the Base (48) with a
S
ilver Ground Screw (27).
P
ress the indicated grommet into the Right
Upright (36).
Slide the Right Base Leg Cover (102) onto the
Base (48) as shown. Attach the Right Base Leg
Cover with three 1/2" Screws (6). Be careful not
to pinch the Upright Wire (28). Do not over-
tighten the Screws.
102
48
28
36
6
6
G
rommet
Ground Wire
6
1
4
27
