5
M6 Washer (28)
M10 Nylon
Locknut (2)
M10 x 180mm Bolt (23)
M8 x 40mm Bolt (25)
M10 Washer (30)
M8 Nylon
Locknut (29)
M4 x 15mm
Screw (20)
M8 Washer (27)
M6 x 25mm
Screw (21)
M6 x 45mm Screw (22)
M8 x 15mm
Screw (19)
M6 x 60mm Screw (24)
M8 x 70mm Carriage Bolt (26)
PART IDENTIFICATION CHART
See the drawings below to identify small parts used in assembly. The number in parentheses by each drawing is
the key number of the part, from the PART LIST near the end of this manual. Note: Some small parts may
have been preattached. If a part is not in the parts bag, check to see if it has been preattached.
