10 - RDM FUNCTIONS
The product can communicate using RDM (Remote Device Management) protocol over a DMX512
Networks.
RDM is a bi-directional communications protocol for use in DMX512 control systems, it is the open
standard for DMX512 device conguration and status monitoring.
The RDM protocol allows data packets to be inserted into a DMX512 data stream without affecting
existing non-RDM equipment. It allows a console or dedicated RDM controller to send commands to
and receive messages from specic xtures.
The PIDs in the following tables are supported in the product.
CATEGORY PARAMETER PID GET SET
Product
Information
DEVICE_INFO 0x0060 x
DEVICE_MODEL_DESCRIPTION 0x0080 x
MANUFACTURER_LABEL 0x0081 x
DEVICE_LABEL 0x0082 x x
FACTORY_DEFAULTS 0x0090 x x
SOFTWARE_VERSION_LABEL 0x00C0 x
DMX512
Setup
DMX_PERSONALITY 0x00E0 x x
DMX_PERSONALITY_DESCRIPTION 0x00E1 x
DMX_START_ADDRESS 0x00F0 x x
Dimmer
Settings
CURVE 0x0340 x x
CURVE_DESCRIPTION 0x0341 x x
MODULATION_FREQUENCY 0x0342 x x
MODULATION_FREQUENCY_ DESCRIPTION 0x0343 x
Sensors
SENSOR_DEFINITION 0x0200 x
SENSOR_VALUE 0x0201 x x
Display Set-
tings
DISPLAY_INVERT 0x0500 x x
Control
IDENTIFY_DEVICE 0x1000 x x
FULL ON
0:HB Mode 1:Studio Mode
0x8217 x x
