PROLIGHTS - EclFresnel TW / PTW06
2 - TECHNICAL DRAWING
283 mm
[11.1 in]
439 mm
[17.3 in]
100 mm
[3.9 in]
539 mm
[21.2 in]
343 mm
[13.5 in]
283 mm
[11.2 in]
100 mm
[3.9 in]
435 mm
[17.1 in]
535 mm
[21.1 in]
342 mm
[13.4 in]
558 mm
[21.9 in]
343 mm
[13.5 in]
285 mm
[11.2 in]
552 mm
[21.7 in]
Fig. 01
ECLFRESNELPTW - Weight: 9.7 kg - 21.38 lbs
ECLFRESNELTW - Weight: 7.5 kg / 16.53 lbs
